22CCT6 SteamChef

$10,924.00

Boilerless Connectionless Convection Steamer

SteamChef 6, model 22CCT6 connectionless (manual water fill and drain) boilerless convection steamer. Capacity for six 2.5″ (1/1 G/N, 65 mm) full size steamtable pans. Patented KleanShield clean cavity protection with manual bypass tray. Standard with SureCook Load Compensating Thermostat. Stand pipe Safety overflow drain eliminates compartment wateroverflow. 12kW electric heating elements cast into inaluminum blocks. Heavy-duty 14-gauge stainless steel cooking compartment door and latch. 5″ AdjustableLegs. 4” deep solid Drain Pan.

Description

Capacity
– 6 each 2.5” x 12” x 20” steam table pans- 4 each 4” x 12” x 20” steam table pans- 3 each 6” x 12” x 20” steam table pans
Manual water fill and drain
No water or drain connection required
Drain pan
4″ deep solid drain pan for manual drain (required for proper operation of steamer)
Fan forced convection steam
with exclusive baffle system for superior steam circulation
Large 3 gallon water reservoir
KleanShield
Patented “KleanShield” eliminates flavor transfer and foaming caused bycontamination of the water reservoir.
Manual Bypass Plate (to bypass KleanShield)
Standpipe Safety Overflow Drain
eliminates water overflow from cooking compartment
SureCook Load Compensating Thermostat
eliminates guesswork for cooking times
Timed and Manual Bypass Switch
for continuous cooking
Exclusive “Self-Adjusting” door
two-piece compartment door with FreeFloating inner door and reversible door gasket extends gasket life 4-times
Heavy Duty 14-gauge stainless steel construction
Left Hand Door Hinging, Controls on the Right
High temperature safety shut off and reset button.
208 – 240-volt, 12 kW, 3 phase standard
5” skid resistant adjustable legs
Stand or Counter Top Mounted

Additional information

W x D x H

21 31/50" X 30 19/100" X 31 13/20"

Power Input Type

Electric

Primary Power Input

208-240 V X 60 Hz x 3 PH

Accessories

34" High Equipment Stand
34" (864mm) High Stainless Steel Stand, for one 22CET3.1 (UNISTAND34)
Unistand25
25" high equipment stand
Pull out shelf for Unistands
Pan rack kit for Unistands
5 foot cord and plug
480 Volt option
Single phase option



Cleveland Buyers Guide Cleveland-Buyers-Guide
Cleveland Warranty Warranty-Update-May-20-2024

Disclaimer 3/20/25

Specification Sheets KE004046-130-22CCT6-1 (1)
Operating Instructions KE004049-2 (1)
SteamChef 6 Flyer 7159-new-steamchef-broch-04-2019
