SGL30T1: PowerPan™ Series Braising Pan & Tilting Skillet with EasyTouch

Coming End of 2025



PowerPan™ Gas Tilting Braising Pan & Skillet, 35″ Rim Height, Available in Both 30 & 40 Gallon

New easyTouch 7″ UI interface streamlines operations with an intuitive touch display and a variety of cooking modes. Key features include a Product Temperature Probe with the ability to control temperature probe ±1°F, Press & Go Recipes with built-in cookbook storage, Multi-Step Cooking with option for customizable messages between cook stages, and Self Diagnostics & Maintenance for real-time error and event logging. Tilting Skillet Model Complete with Dual Power Setting, Normal and High Power Cooking Controls, Power Burner (Forced-Air) Gas Combustion System, Automatic Ignition, Splash-Proof Construction, Spring Assist Cover with Vent, Gallon/Liter Markings, 5/8″ Stainless Steel Clad Cooking Surface with Bead Blasted Finish, Easy to use Manual Hand Tilt with Enclosed Permanently Lubricated Gearbox, Adjustable Feet with Rear Flanged and Front Bullet Style. Tilting Skillet Model Complete with Dual Power Setting, Normal and High Power Cooking Controls, Power Burner (Forced-Air) Gas Combustion System, Automatic Ignition, Splash-Proof Construction, Spring Assist Cover with Vent, Gallon/Liter Markings, 5/8″ Stainless Steel Clad Cooking Surface with Bead Blasted Finish, Easy to use Manual Hand Tilt with Enclosed Permanently Lubricated Gearbox, Adjustable Feet with Rear Flanged and Front Bullet Style.

Description

Cooking Surface
5/8″ Stainless Steel Bead Blasted cooking surface prevents warping and keeps food from sticking.
Pan Construction
Durable 12 gauge, 304 Stainless Steel pan construction. 5/8″ (16mm) mild steel clad bottom plus a 1/16″ (1.6mm). Stainless Steel plate for even temperature distribution.
Low Height
Low 35″ rim height for easy operation and cleaning.
Controls
easyTouch 7″ UI display interface is conveniently located in a Drip Proof Side Console. Temperature controlled up to 425°F (220°C). New easyTouch UI interface simplifies operations with accurate touch tune and various cooking modes, including Product Temperature Probe with the ability to control temperature probe ±1°F, Press & Go Recipes with cookbook storage, Multi-Step Cooking with option to add message between cook stages, and Self Diagnostics & Maintenance for error and event logging.
Safety Tilt Feature
Easy-to-turn manual hand tilt with enclosed permanently lubricated gearbox. Optional power tilt with manual override available.
Volume Markings
Gallon/Liter Markings and Vented Spring Assist Cover standard.
Optional Valve Available
Optional 2″ Tangent Draw-Off Valve available.
Cooking Feature
10° Cooking Feature. Tilt unit up to 10° without the power being turned off.
Temperature Control
Adjustable Solid State. Thermostat accurately controls temperature from 140°F to 425°F.
Cover
Spring-Assist Cover with full width handle and vent.
Power Burner
Exclusive Ultra Efficient Power Burner (Forced-Air) Gas Combustion System with Automatic Ignition.
Dual Power Settings
Exclusive Dual Power Settings: 90,000 and 125,000 Btu for 30 gallons, 160,000 Btu and 200,000 Btu for 40 gallons provides superior heat-up and recovery.
Open Design
Open base design for easy cleaning and maintenance.
Cord & Plug
Supplied with Cord & Plug for 115-volt controls.
Spark Ignition
Electronic “Spark Ignition System Standard”.

Additional information

Power Input Type

Electric

Accessories

Draw-Off Valve
2" (50 mm) Tangent Draw-Off Valve (TD2SK)
Faucet
Double or Single Pantry Faucet (SPS14, DPS14), includes Faucet Mounting Bracket.
Faucet Bracket
(FBKT1)
Pan Carrier
(PCS)
Poaching Pans
(PP).
Power Tilt
With Manual Override (PT2)
Spray Head
Hot & Cold Water Pre-Rinse Spray Head with Hose (PRS-S)
Vegetable Steamer Baskets
(VS)
