Description
| Water Resistant Controls Splash-proof construction |
| Pouring Lip Large pouring lip for high capacity and chunky products. |
| Rolled Rim Re-inforced rolled rim design prevents damage to kettle rim, eliminates “bar rim designs” |
| Heating Elements Welded-in heating elements, (holds vacuum better, won’t leak or loose water) |
| Easily Cleaned Kettle and all exterior surfaces are of type 304 stainless steel with an #4 finish |
| Pressure Gauge Rear mounted easy access pressure gauge and pressure relief valve to prevent tampering. Color coded easy to read pressure gauge with “green” and “vent air zone” |
| Jacket Rating 50 psi steam jacket rating for higher cooking temperatures |
| Safety Valve 50 psi |
| Water Level Control Solid state water level control (no sight glass gauge to break or leak) |
| Element Cover Splash proof element cover with a double gasket seal |
| Standard voltage 208-240 volts, 60 Hz, 3 phase, 3 wire. Model KET-6 and KET-12 are field rewirable to single phase |
| Self-Contained Electric Steam Source Easily installed – needs only an electrical hook-up |
| 50 PSI Steam Jacket (3.5 Bar Boiling Pan) for Faster Cooking Steam jacket filled with treated water, venting and/or refilling is not required |
| State of the Art Controls Accurate, consistant solid state temperature controls (mechanical thermostate not as accurate) – less than ±1°C variance (ideal for simmering). Operating temperature range from 145° – 260°F (63°C – 127°C) Control panel includes:LED indicator for heat cycle, LED indicator for low water Power ON/OFF switch, Adjustable temperature control dial |
| Legs 1 5/8″ O.D. quad-leg supports with level adjustable feet for floor bolting |
| Shipping Weights, kw’s, Dims. (W x D X H) Model KEL25, 210 lbs (95 kgs), 9.8kW’s, 30″ (759mm) x 22″ (556 mm) x 37″ (934mm)Model KEL40, 280 lbs (127 kgs), 14.7kW’s, 31″ (782mm) x 29″ (740 mm) x 40″ (1016mm)Model KEL60, 330 lbs (150 kgs), 14.7kW’s, 34″ (870mm) x 33″ (839 mm) x 43″ (1093mm)Model KEL80, 385 lbs (175 kgs), 14.7kW’s, 38″ (959mm) x 37″ (931 mm) x 44″ (1105mm)Model KEL100, 415 lbs (195 kgs), 14.7kW’s, 40″ (1023mm) x 39″ (997mm) x 45″ (1144mm) |
